Specifications

• Dimensions

  add remove
  • Length:
    2135 mm
  • Seat height, unladen:
    820 mm
  • Ground clearance:
    153 mm
  • Rake:
    24.5
  • Trail:
    100.4 mm
  • Wheelbase:
    1485 mm
  • Tyres, front specifications:
    120/70-ZR17/58W
  • Tyres, rear specifications:
    160/60-ZR17/69W
  • Fuel capacity:
    13.1 l
  • Oil capacity:
    2.5 l
  • Weight, as shipped:
    199 kg
  • Weight, in running order:
    208.20 kg
  • Tyre, type:
    Maxxis Supermaxx ST
  • Static ground clearance:
    153 mm
• Engine

  add remove
  • Engine:
    Liquid-cooled, Parallel-Twin, 500cc
  • Bore:
    69 mm
  • Stroke:
    66.8 mm
  • Displacement:
    500 cc
  • Compression ratio:
    11.5:1
  • Fuel system:
    Electronic Sequential Port Fuel Injection (ESPFI)
  • Exhaust:
    2 into 1 short single, 3 catalyst
• Performance

  add remove
  • Engine torque testing method:
    GB/T20076-2006, GB/T5363-2008
  • Engine torque:
    46 Nm
  • Engine torque (RPM):
    6000
  • Horsepower:
    47 HP / 35 kW @ 8500 rpm
  • Lean angle, right (deg.):
    46.9
  • Lean angle, left (deg.):
    49.5
  • Fuel economy testing method:
    WMTC
  • Fuel economy:
    4.85 l/100 km
  • CO₂ emissions testing method:
    WMTC
  • CO₂ emissions:
    112 g/km CO₂
• Drivetrain

  add remove
  • Primary drive:
    Chain, 74/38
  • Engine torque:
    46 Nm
  • Gear ratios (overall) 1st:
    2.85
  • Gear ratios (overall) 2nd:
    1.95
  • Gear ratios (overall) 3rd:
    1.56
  • Gear ratios (overall) 4th:
    1.33
  • Gear ratios (overall) 5th:
    1.19
  • Gear Ratios (overall) 6th:
    1.08
• Chassis

  add remove
  • Front fork:
    50mm upside down rebound adjustable
  • Rear shocks:
    Oil and gas separation type, rebound damping adjustable, preload adjustable shock absorber
  • Wheels, front type:
    Cast aluminium
  • Wheels, rear type:
    Cast aluminium
  • Brakes, type:
    Front floating, rear solid
  • Brakes, caliper type:
    4-piston fixed front and 1-piston floating rear
• Electric

  add remove
  • Lights (as per country regulation), indicator:
    All LED, low beam, high beam and signature position lamp. All LED Tail/Stop, front signal lights and rear turn signals.
  • Gauges:
    Combined electronic instrument stepper motor indicating vehicle speed, digital indicates rpm, hour, total trip, two trips (A + B), km/mile indication
