Specifications

• Dimensions

  add remove
  • Length:
    2615 mm
  • Ground clearance:
    125 mm
  • Rake:
    26
  • Trail:
    101 mm
  • Wheelbase:
    1670 mm
  • Tyres, front specifications:
    MT 130/60B19 M/C 61H
  • Tyres, rear specifications:
    P215/45R18 83T
  • Fuel capacity:
    22.7 l
  • Oil capacity:
    4.0 l
  • Weight, as shipped:
    488 kg
  • Weight, in running order:
    503.49 kg
  • Luggage capacity – volume:
    2 cu ft (0.06 m³)
  • Tyre, type:
    Dunlop Harley-Davidson Series, bias blackwall front and radial blackwall rear
• Engine

  add remove
  • Engine:
    Milwaukee-Eight® 114
  • Bore:
    102 mm
  • Stroke:
    114 mm
  • Displacement:
    1868 cm³
  • Compression ratio:
    10.5:1
  • Fuel system:
    Electronic Sequential Port Fuel Injection (ESPFI)
  • Exhaust:
    Shorty slash down-style chrome finish mufflers
• Performance

  add remove
  • Engine torque testing method:
    EC 134/2014
  • Engine torque:
    165 Nm
  • Engine torque (RPM):
    2750
  • Horsepower:
    90 HP / 67 kW @ 4750 rpm
  • Lean angle, right (deg.):
    N/A
  • Lean angle, left (deg.):
    N/A
  • Fuel economy testing method:
    EU 134/2014
  • Fuel economy:
    42.8 mpg (5.5 l/100km)
  • CO₂ emissions testing method:
    EU 134/2014
  • CO₂ emissions:
    151 g/km CO₂
• Drivetrain

  add remove
  • Primary drive:
    Chain, 34/46 ratio
  • Gear ratios (overall) 1st:
    10.534
  • Gear ratios (overall) 2nd:
    7.302
  • Gear ratios (overall) 3rd:
    5.423
  • Gear ratios (overall) 4th:
    4.392
  • Gear ratios (overall) 5th:
    3.741
  • Gear Ratios (overall) 6th:
    3.157
• Chassis

  add remove
  • Front fork:
    49mm dual bending valve
  • Rear shocks:
    Hand-adjustable emulsion rear suspension
  • Wheels, front type:
    Cast aluminum
  • Wheels, rear type:
    Cast aluminum
  • Brakes, type:
    Dual floating rotors (front), fixed rotor (rear)
  • Brakes, caliper type:
    Front: 32mm 4 piston fixed, Rear: floating 36mm piston integrated park brake
• Electric

  add remove
  • Lights (as per country regulation), indicator:
    Dual halogen headlight 55-watt 625 lumen low beam, 65-watt 1,570 lumen high beam; Incandescent
  • Gauges:
    Speedometer, fuel gauges; display features odometer, trip A, trip B, range to empty, and gear indicator
