Specifications

• Dimensions

  add remove
  • Length:
    2410 mm
  • Overall width:
    975 mm
  • Overall height:
    1350 mm
  • Seat height, unladen:
    711 mm
  • Ground clearance:
    140 mm
  • Rake:
    26
  • Trail:
    170 mm
  • Wheelbase:
    1625 mm
  • Tyres, front specifications:
    130/60B19 M/C 61H
  • Tyres, rear specifications:
    180/55B18 M/C 80H
  • Fuel capacity:
    22.7 l
  • Oil capacity:
    4.2 l
  • Weight, as shipped:
    363 kg
  • Luggage capacity – volume:
    2.2 cu ft (0.062 m3)
  • Tyre, type:
    Dunlop® Harley-Davidson Series, bias blackwall front and rear
  • Fork angle:
    30
  • Reserve fuel capacity, fuel injection:
    3.8 l
• Engine

  add remove
  • Engine:
    Milwaukee-Eight® VVT 121
  • Bore:
    103.5 mm
  • Stroke:
    117.5 mm
  • Displacement:
    1977 cm³
  • Compression ratio:
    11.4:1
  • Fuel system:
    Electronic Sequential Port Fuel Injection (ESPFI)
  • Air cleaner:
    Synthetic Felt, Washable
  • Exhaust:
    2-1-2 dual exhaust
  • Lubrication system:
    Pressurized, dry-sump
• Performance

  add remove
  • Engine torque testing method:
    J1349
  • Engine torque:
    189 Nm
  • Engine torque (RPM):
    3,000
  • Horsepower:
    115 HP / 86 kW @ 4500 rpm
  • Lean angle, right (deg.):
    32
  • Lean angle, left (deg.):
    32
  • Fuel economy testing method:
    Estimated City/Hwy
  • Fuel economy:
    45 mpg (5.1 l/100 km)
• Drivetrain

  add remove
  • Primary drive:
    Chain, 34/46 ratio
  • Gear ratios (overall) 1st:
    9.593
  • Gear ratios (overall) 2nd:
    6.65
  • Gear ratios (overall) 3rd:
    4.938
  • Gear ratios (overall) 4th:
    4
  • Gear ratios (overall) 5th:
    3.407
  • Gear Ratios (overall) 6th:
    2.875
  • Final drive:
    Belt, 32/68 ratio
  • Clutch:
    Mechanically actuated 10 plate, wet Assist & Slip
  • Transmission:
    6-Speed Cruise Drive®
• Chassis

  add remove
  • Front fork:
    47 mm Inverted 1x1 Front Forks
  • Rear shocks:
    Dual adjustable emulsions suspension with remote preload adjustment on the left shock, and threaded preload on the right shock
  • Wheels, front type:
    Combo Cast Laced
  • Wheels, rear type:
    Combo Cast Laced
  • Brakes, type:
    Dual floating rotors (front), fixed rotor (rear)
  • Brakes, caliper type:
    32 mm, 4-piston fixed dual radially mounted front, and single axially mounted rear
  • Frame:
    Mild steel; tubular frame, two-piece stamped and welded backbone; cast and forged junctions; twin down tubes; bolt-on rear frame with forged fender supports; MIG welded
  • Swingarm:
    Mild steel, two piece drawn and welded section; forged junctions; MIG welded
• Electric

  add remove
  • Lights (as per country regulation), Headlamp:
    LED
  • Lights (as per country regulation), Tail/Stop:
    LED
  • Lights, front signal lights:
    LED
  • Lights, rear turn signals:
    LED
  • Gauges:
    Digital gauges integrated within the display
  • Battery:
    Sealed, maintenance-free, 12V, 28-amp/hour, 405 cca (per Battery Council International Rating)
  • Charging:
    Three-phase, 58-amp system (754W max power @ 13V)
  • Starting:
    1.6 kW electric with solenoid shift starter motor engagement
  • Electric power outlet:
    15 Watt USB-C electric power accessory port in media storage box.
  • GPS System:
    Yes, imbedded navigation system with real-time traffic and weather via Wi-Fi Hotspot
• Infotainment

  add remove
  • Screen size:
    12.3 in (312 mm)
  • Infotainment system:
    Skyline™ OS
  • Type:
    Full Color TFT
  • Watts per channel:
    125
  • Speakers:
    4
  • Speaker size:
    Two 6.5in fairing speakers, and two 5x7in saddlebag speakers
  • Headset specifications (if equipped):
    Harley-Davidson Packtalk Edge wireless Bluetooth® headset
  • AM:
    Standard
  • FM:
    Standard
  • Weather Band (WB):
    Supported
  • Languages:
    Arabic, Bahasa (Indonesian), Catalan, Chinese (Simplified/Traditional), Czech, Danish, Dutch, English (UK/USA default), Finnish, French (Canada/France), German, Hebrew, Hungarian, Indonesian, Italian, Japanese, Korean, Malay, Norwegian, Polish, Portuguese
  • Hands-free mobile phone — via Bluetooth:
    Standard
  • Voice recognition: phone functions only:
    Phone dependent
  • Voice Recognition Languages: Tuner / Media / Navigation:
    Phone dependent
  • Text-to-Speech (TTS) languages:
    Phone dependent
  • Rider / passenger intercom:
    Standard (passenger headset sold separately), VOX is available for HD headsets
  • Vehicle information screen:
    Standard
  • USB:
    USB-C/MTP/iPod/iPhone, any device with proper adapters to the electric power outlet located in the inner fairing storage.
  • Bluetooth:
    Phone/Media Player, Headset
