Specifications

• Dimensions

  add remove
  • Length:
    2225 mm
  • Ground clearance:
    105 mm
  • Rake:
    30
  • Trail:
    107 mm
  • Wheelbase:
    1530 mm
  • Tyres, front specifications:
    130/90B16 73H
  • Tyres, rear specifications:
    150/80B16 77H
  • Fuel capacity:
    17 l
  • Weight, as shipped:
    255 kg
• Engine

  add remove
  • Engine:
    Air-cooled, Evolution™
  • Bore:
    88.9 mm
  • Stroke:
    96.8 mm
  • Displacement:
    1202 cm³
  • Compression ratio:
    10:01
  • Fuel system:
    Electronic Sequential Port Fuel Injection (ESPFI)
  • Exhaust:
    Chrome, staggered, shorty exhaust with dual mufflers
• Performance

  add remove
  • Engine torque testing method:
    EC 134/2014
  • Engine torque:
    96 Nm
  • Horsepower:
    67 HP / x50 Kw @ 6000 rpm
  • Lean angle, right (deg.):
    26.2
  • Lean angle, left (deg.):
    28.3
  • Fuel economy testing method:
    EU 134/2014
  • CO₂ emissions testing method:
    EU 134/2014
  • CO₂ emissions:
    120 g/km CO2
• Drivetrain

  add remove
  • Primary drive:
    Chain, 38/57 ratio
  • Gear ratios (overall) 1st:
    9.004
  • Gear ratios (overall) 2nd:
    6.432
  • Gear ratios (overall) 3rd:
    4.783
  • Gear ratios (overall) 4th:
    3.965
  • Gear ratios (overall) 5th:
    3.4
• Chassis

  add remove
  • Wheels, front type:
    Black Steel Laced
  • Wheels, rear type:
    Black Steel Laced
  • Brakes, caliper type:
    Dual-piston front, Dual-piston rear
• Electric

  add remove
  • Lights (as per country regulation), indicator:
    High beam, neutral, low oil pressure, turn signals, engine diagnostics, low fuel warning, low battery, security system, ABS
  • Gauges:
    Handlebar-mounted electronic speedometer with odometer, time-of-day clock on odometer, dual tripmeter, low fuel warning light, low oil pressure light, engine diagnostics readout, LED indicator lights
